Description

Application:

Mainly used for tube and bottle packaging of liquids and pastes. For example, reagents, plastic test tubes, eye drops, e-liquids, essential oils and other small bottled products. Combination with other devices can achieve production line operation.

Kindly Reminder:

We have experienced team of R & D engineers who can customize packaging solutions according to your product characteristics.

Packing Exambers:

Automatic IVD Reagents Liquid Filling And Capping Machine

1. This Automatic Reagent Filling Machine Reagent Tube Filling Capping Machine has adopted advanced technology. It has compact structure and is convenient to replace.

2. This Automatic Reagent Filling Machine Reagent Tube Filling Capping Machine is the main liquid filling production line, which complies with ‘GMP’ requirements. This machine adopts high-quality 304 stainless steel materials;

3.  Advanced design and compact structure are features of the filling machine. Replacement is very convenient. Combination with other devices can achieve production line operation.

4. The operation of the machine is equipped with safety guarantees, fault alarms and other settings. The automatic operation of functions from pipe entry, filling, cap sorting, capping, capping, labeling, and collection, does not require manual intervention.

Parameter

Suitable for tube size according to the sample provided by the customer, it can be customized
How to organize the pipes manually place the pipes on the pipe-organizing machine
Out of the tube according to the shape of the tube, actual customization
Filling method 2 heads peristaltic pump filling
Filling capacity 3ml~8ml
Output about 2400 bottles/hour
The way to arrange the cap automatic lid arrangement with vibration plate (double vibration plate)
Cap removal/cap removal method: automatic cap removal, servo torque capping (double-head servo, torque capping)
Labeling automatic positioning and labeling
Pipe-out method the cylinder grabs the pipe and moves the pipe, and the pipe is discharged through the slope.
Program control touch screen
Air pressure 0.6-0.8MPa
Power about 3KW/AC220V 50/60HZ

The Automatic IVD Reagents Liquid Filling and Capping Machine is a sophisticated packaging solution that is designed for use in the in-vitro diagnostic reagents industry. This machine is capable of filling various types of liquid reagents into containers, such as vials and bottles, and sealing them with precision.

The machine has a high-precision liquid filling system that can accurately fill the reagents with a high degree of accuracy. The filling system can handle different types of liquids, including corrosive and viscous liquids. The filling process is done using a peristaltic pump, which ensures that the liquid is filled to the desired level without any spillage or wastage.

The capping system of this machine is also advanced and can handle different types of caps, including screw caps, press caps, and snap caps. The capping process is done using a pneumatic capping head, which applies the caps to the containers with precision and consistency.

The Automatic IVD Reagents Liquid Filling and Capping Machine also features a PLC control system that allows the user to control the various aspects of the packaging process, including the filling and capping speed, filling volume, and capping torque. The machine also has a touch screen interface that makes it easy for the user to operate and monitor the packaging process.

In addition, the machine is designed to meet the cGMP standards and is made of high-quality materials that are corrosion-resistant and durable. The machine is easy to clean and maintain, which reduces downtime and ensures that the packaging process runs smoothly.

Overall, the Automatic IVD Reagents Liquid Filling and Capping Machine is a reliable and efficient packaging solution that is suitable for use in the in-vitro diagnostic reagents industry.
