Horizontal Flow Wrap Machine, Flow Wrapping Equipment
Description
Application:
Suitable for packing soft, sticky or multi pack products such as towel, tissue, noodles, egg rolls, sausages, ice lolly, ice cream bar, soft candy, cutlery, vegetables, etc.
Kindly Reminder:
We have experienced team of R & D engineers who can customize packaging solutions according to your product characteristics.
Packing Exambers:
Dual frequency conversion control, bag length can be setted and cutting in one step,saving time and films.
Interface features are easy and quick setting and operating.
Self diagnosis failure function, clear failure display.
High sensitivity photoelectric eye color tracing,numerical input of cutting sealing position for extra accuracy.
Temperature independent PID control, suitable for packing different materials.
Positioned stop function,without sticking knife or wasting film.
Simple driving system,reliable working,convenient maintenance.
All control is realized through software,easy for function adjusting and technical upgrade.
Parameter
| Model | 450X | 600X | 700X |
| Film width | Max.450mm | Max.600mm | Max.700mm |
| Bag length | 120-450mm | 120-500mm | 120-600mm |
| Bag width | 50-180mm | 100-280mm | 100-330mm |
| Product height | Max.80mm | Max.110mm | |
| Max width of film roll | Max.320mm | ||
| Packing speed | 40-150bags/min | 20-150bags/min | 20-130bags/min |
| Power | 220V,50/60Hz,2.8KW | ||
| Machine size (L*W*H)mm | 4020*820*1450 | 4020*920*1460 | 4020*980*1480 |
| Machine weight | 650kg | 680kg | 720kg |
A Horizontal Flow Wrap Machine, also known as a Flow Wrapping Equipment, is a versatile packaging machine used in various industries. The machine is designed to wrap and package different products, such as food items, pharmaceuticals, and household items, in a flexible packaging material. With its high-speed operation, precise wrapping capabilities, and flexibility in handling different product sizes and shapes, the machine offers numerous benefits to manufacturers and end-users.
1. How Does a Horizontal Flow Wrap Machine Work?
A Horizontal Flow Wrap Machine works by feeding the product onto a conveyor belt, which then moves it towards the sealing area. The sealing area consists of a pair of heated rollers that seal the packaging material around the product. The machine then cuts the packaging material, creating a sealed package that moves along the conveyor belt towards the end of the machine. The speed of the conveyor belt can be adjusted to accommodate different product sizes and packaging materials.
2. Features of a Horizontal Flow Wrap Machine
A Horizontal Flow Wrap Machine comes with several features that make it an ideal choice for packaging different products. Some of the features include:
High-Speed Operation
The machine can operate at high speeds, ranging from 20 to 300 packages per minute, depending on the product size and packaging material.
Flexibility in Handling Different Product Sizes and Shapes
The machine can handle different product sizes and shapes, such as irregularly shaped products, using customized feeding and cutting mechanisms.
Precise Wrapping Capabilities
The machine offers precise wrapping capabilities, ensuring that the packaging material is wrapped tightly around the product, reducing the risk of contamination and improving product safety.
Compatibility with Different Packaging Materials
The machine is compatible with different packaging materials, such as plastic films, laminates, and aluminum foil, providing flexibility in packaging options.
Easy Operation and Maintenance
The machine is easy to operate, with user-friendly controls and minimal maintenance requirements.
3. Applications of a Horizontal Flow Wrap Machine
A Horizontal Flow Wrap Machine can be used in various applications, including:
Food Packaging
The machine is ideal for packaging different food items, such as baked goods, confectionery items, and snacks.
Pharmaceutical Packaging
The machine can also be used to package pharmaceutical products, such as tablets, capsules, and medical devices.
Household Item Packaging
The machine can package different household items, such as soap bars, cleaning wipes, and toiletries.
Other Product Packaging
The machine can also be used to package other products, such as stationery items, toys, and electronic components.
4. Benefits of Using a Horizontal Flow Wrap Machine
Using a Horizontal Flow Wrap Machine offers numerous benefits, including:
Cost Savings
The machine reduces labor costs and material waste, improving the overall cost-effectiveness of the packaging process.
Improved Productivity
The machine operates at high speeds, increasing the packaging output and reducing downtime.
Consistent Quality
The machine offers precise wrapping capabilities, ensuring consistent product quality and reducing the risk of product damage during transportation and storage.
Flexibility in Packaging Options
The machine can handle different product sizes and shapes, as well as different packaging materials, providing flexibility in packaging options.
Enhanced Product Safety
The machine ensures that the product is packaged in a hygienic manner, reducing the risk of contamination and improving product safety.
5. Conclusion
A Horizontal Flow Wrap Machine is a valuable asset in various industries, providing high-speed operation, precise wrapping capabilities, and flexibility in handling different product sizes and packaging materials. Its applications extend beyond food packaging, making it a versatile machine for different product packaging needs. Using the machine offers numerous benefits, including cost savings, improved productivity, consistent quality, flexibility in packaging options, and enhanced product safety.
